Flowserve Logix 3400MD - Maintenance and Repair; 8.1 Driver Module Assembly; Driver Module Assembly Replacement

35
Logix 3400MD Digital Positioner FCD LGENIM3404-00 – 9/09
flowserve.com
Fieldbus
Block
Index
Fieldbus Variable
Name
Transducer
Block
Fieldbus
Datatypes
Logix Positioner
R/W Description
Register Type
Fix
Pt
Rd
Variable Name
N/A N/A N/A N/A 192 U_CHAR NO P2IN_ N/A Test, Direct I/O, Port 2
N/A N/A N/A N/A 193 U_CHAR NO P3IN_ N/A Test, Direct I/O, Port 3
N/A N/A N/A N/A 194 U_CHAR NO P4IN_ N/A Test, Direct I/O, Port 4
N/A N/A N/A N/A 195 U_CHAR NO P5IN_ N/A Test, Direct I/O, Port 5
N/A N/A N/A N/A 196 U_CHAR NO P6IN_ N/A Test, Direct I/O, Port 6
N/A N/A N/A N/A 197 U_CHAR NO P7IN_ N/A Test, Direct I/0, Port 7
N/A N/A N/A N/A 198 U_CHAR NO P8IN_ N/A Test, Direct I/O Port 8
Parameters reserved for Future Use
108 MISC_CONFIG XDTB_MAIN BIT_STRING 160 U_CHAR NO Misc_Config NRW Reserved Flags for Future Use
46 RESERVED XDTB_MD FLOAT N/A N/A N/A N/A RW Reserved for Future Use
47 RESERVED XDTB_MD FLOAT N/A N/A N/A N/A RW Reserved for Future Use
48 RESERVED XDTB_MD FLOAT N/A N/A N/A N/A RW Reserved for Future Use
49 RESERVED XDTB_MD FLOAT N/A N/A N/A N/A RW Reserved for Future Use
45 RESERVED XDTB_MD FLOAT N/A N/A N/A N/A RW Reserved for Future Use
27 RESERVED XDTB_MAIN FLOAT N/A N/A N/A N/A RW Reserved for Future Use
39 RESERVED XDTB_MAIN FLOAT N/A N/A N/A N/A RW Reserved for Future Use
105 RESERVED XDTB_MAIN FLOAT N/A N/A N/A N/A RW Reserved for Future Use
106 RESERVED XDTB_MAIN FLOAT N/A N/A N/A N/A RW Reserved for Future Use
110 RESERVED XDTB_MAIN FLOAT N/A N/A N/A N/A RW Reserved for Future Use
112 RESERVED XDTB_MAIN FLOAT N/A N/A N/A N/A RW Reserved for Future Use
Definitions:
XDTB_MAIN - Main Transducer Block - Contains parameters used •
mostly for command.
XDTB_TECH - Technician Transducer Block - Contains diagnostics and
uncommon setup parameters
XDTB_MD - MD Transducer Block - Contains the PRO diagnostic
parameters
R - Parameter is Readable
W - Parameter is Writeable
N - Parameter is Non-Volatile
S - Parameter is Static as defined by the Fieldbus Specification.
N/A - Not ApplicableXDTB_TECH - Technician Transducer Block -
Contains diagnostic and uncommon setup parameters.
XDTB_MD - MD Transducer Block - Contains the PRO diagnostic •
parameters.
R - Paramater is Readable•
W - Parameter is Writable•
N - Parameter is Non-Volatile•
S - Paramter is Static as defined by the Fieldbus Specification•
N/A - Not Applicable•
8 Maintenance and Repair
8.1 Driver Module Assembly
The driver module assembly moves the spool valve by means of a
differential pressure across its diaphragm. Air is routed to the driver
module from the regulator through a flexible hose. A barbed fitting
connects the flexible hose to the driver module assembly. Wires
from the driver module assembly connect the hall effect sensor and
the piezo valve modulator to the main PCB assembly.
Driver Module Assembly Replacement
To replace the driver module assembly, refer to Figures 12-16 and 22
and proceed as outlined below. The following tools are required:
• Flatplateorbarabout
1
⁄8” thick
• Phillipsscrewdriver
• ”nutdriver
0
WARNING: Observe precautions for handling electrostatically
sensitive devices.
