Logix 3400MD Digital Positioner FCD LGENIM3404-00 – 9/09
flowserve.com
4.1 Specifications
Table I: Electrical Specifications
Power Supply
Two-wire, 9 to 32 V DC
FF compatible
IS Fisco compliant
Communications FF Protocol ITK 5.1
Operating Current 23 mA
Maximum Voltage
36.0 V DC
9 t0 32 V DC for general use & flameproof applications
9 to 24 V DC for Intrinsically safe applications
9 to 17.5 V DC for Intrinsically safe applications per
FISCO requirements.
Table II: Environmental Conditions
Operating Temperature Range Standard
-40° to 176°F
(-40° to 80°C)
Transport and Storage
Temperature Range
-40° to 176°F (-40° to 80°C)
Operating Humidity 0 - 100% non-condensing
*Note: The Logix 3400MD is designed to operate with clean, dry, oil-free
instrument grade air per ISA 7.0.01-1996 or with dry nitrogen, sweet natural
gas.
Table III: Physical Specifications
Housing Material Cast, powder-painted aluminum, stainless steel
Soft Goods Buna-N / Florosilicone
Weight
8.3 pounds (3.9 kg) aluminum
20.5 pounds (9.3 kg) stainless steel
Table IV: Positioner Specifications
Deadband <0.1% Full Span
Repeatability <0.05% Full Span
Linearity <0.5% (Rotary), <0.8%, (Linear Valve) Full Span
Per ISA 75.25.01-2000
Air Consumption <0.3 SCFM (0.5 Nm
3
/hr) @ 60 psi (4 bar)
Air Supply 30-150 psig (ISA 7.0.0.1 compliant)
Table V: Air Supply Requrements
Dew Point
At least 18
0
F (10
0
C) below minimum anticipated
ambient temperature
Particulate Matter Filtered to 5 microns
Oil Content Less than 1 ppm w/w
Contaminants Free of all corrosive contaminants
Table VI: Function Blocks
AO One Analog Output
DI Two Discrete Inputs
DO One Discrete Output
PID One PID Control Function
OS One Output Splitter
IS One Input Selector
Table VII: Hazardous Area Certifications
Intrinsically Safe
Class I,II,III, Div 1, Grp A,B,C,D,E,F,G
Class I, Zone 0, AEx ia IIC T4
Entity Parameters:
Ui= 24V, Ii=250mA, Pi=1.2W,
Ci=3300pF,
Li=10uH
Fisco Parameters
Ui=17.5V, Ii=380mA, Pi=5.32W,
Ci=3300pF, Li=10uH
NEMA/Type 4X
Explosion Proof
Class I, Div. 1, Grp B, C, D
DIP Class II, III Div. 1 Grp E, F, G
NEMA/Type 4X
Class I, Div 1, Grp B, C, D
Class II, Grp E, F, G
Class III
Ex d IIB + H2
Non Incendive: Class I, II, III, Div 1, Grp, A, B, C, D, F, G
Ta=-20
0
C to +60
0
C
II 1 G, Ex ia IIC T4 Tamb=-20
0
C to 60
0
C
Entity Parameters:
Ui=24V, Ii=250mA, Pi=1.2W, Ci=3300pF,
Li=10uH
Fisco Parameters:
Ui=17.5V, Ii=380mA, Pi=5.32W, Ci=3300pF,
Li=10uH
IP 65
II 2 G, Ex d IIB+H2 T5
Ta=-40
0
C to 80
0
C IP65
II 2 D, Ex tD A21 T95
0
C IP65
Ta=-40
0
C to 55
0
C
NEMA/Type 4X
IECEx
Ex ia IIC T4 Ga
Entitiy Parameters:
Ui=24V, Ii=250mA, Pi=1.2W, Ci=3300pF,
Li=10uH
Fisco Parameters:
Ui=17.5V, Ii=380mA, Pi=5.32W, Ci=3300pF,
Li=10uH
IP 65
Non Incendive
II 3 G, Ex nAnL IIC T6 Ta=-20
0
C to 60
0
C
IP 65
CE Compliant
FISCO Compliant
*NOTE: IP 66 INGRESS PROTECTION IS AVAILABLE. PLEASE
CONTACT FACTORY FOR DETAILS.
®
®
