14 How to Order
Table XVII: How to Order
Selection Code
Example
3
3
Protocol Fo u n d a t i o n Fieldbus* 4
4
Diagnostics
Standard Diagnostics* 0
2
Advanced Diagnostics 1
Pro Diagnostics 2
Housing & Brand
Aluminum, White Paint (Valtek)* 0
0
Stainless Steel, No Paint (Valtek) 1
Aluminum, Black Paint (Automax) 2
Aluminum, Food Grade White Paint (Automax) 3
Aluminum, Accord (Black Paint) 4
Aluminum, Accord (Food-Grade White Paint) 5
Aluminum - Off Shore Paint 6
Design Version MD
MD
Certifications
Explosionproof Class I, Div 1, Groups B, C, D,
DIP Class II, III, Division 1 E, F, G
01
1
Intrinsically Safe Class I, Div 1, Groups A,B,C,D
Nonincendive Class I, II, III, Division 2 A, B, C, D, E, F, G
02
INMETRO BR-EX ia IIC T4/T5; BR-Ex d IIB+H2 T5 (South America) 06
Flame Proof EEx d IIB+H2; ATEX II 2 G 07
General Purpose 14
Ex ia IIC, ATEX II 1 G 15
Ex nA nL IIC, ATEX II 3 G 20
IECEx Ex ia IIC 21
Shaft/Feedback Shaft
DD 316 SSl Shaft (Valtek Standard)* D6
D6
NAMUR 316 SSl (VDI/VDE 3845) N6
Conduit Connections/Threaded Connections
½" NPT E
E
M20 M
Action
4-way (Double-Acting) 04
04
3-way (Single-Acting) 03
4-way Vented (Double-Acting) 4V
3-way Vented (Single-Acting) 3V
Temperature Low -40°C to 85°C (-40°F to 185°F)* 40
40
Gauges
Gauges (Valtek standard)* 0G
0G
SS with SS internals, psi (bar/kPa) 0S
SS with SS internals, psi (kg/cm
2
) KS
SS with brass internals, psi (kg/cm
2
) KG
Stainless Steel 0S
No Gauges 0U
Special Options
None* 00
00
Remote Mount Feedback (Only available with Certification Option 14) RM
Fail Option Feedback** SF
*Indicates Standard Product Configuration
**Contact factory before specifying this option
