Flowserve Logix 3400MD User Manual

Logix 3400MD Digital Positioner FCD LGENIM3404-00 – 9/09
46
Item
No.
Description Quantity
Kit 7: Soft Goods Kit, P/N 199789.999.000
3 O-ring, Main Housing Cover 1
15 O-ring, Pressure Sensor to Housing 2
20 O-ring, Regulator to Housing 1
22 O-ring, User Interface Cover 1
26 O-ring, User Interface Board 1
35 Flexible Tube 1
37 Nylon Washer 1
41 O-ring, Spool Valve to Housing 3
45 Hydrophobic Filter, Spool Valve Chamber 1
46 O-ring, Spool Valve Cover 1
54 O-ring, Feedback Shaft 1
Kit 8: Standard Model Pressure Sensor Plug Plate Kit, P/N 199790.999.000
11 Screw, Pressure Sensor Board 2
14 Pressure Sensor Plug Plate 1
15 O-ring, Pressure Sensor to Housing 2
Item
No.
Description Quantity
Kit 9: Advanced Model Pressure Sensor Board Kit, P/N 199791.999.000
11 Screw, Pressure Sensor Board 2
13 Pressure Sensor Board 1
15 O-ring, Pressure Sensor to Housing 2
Kit 10: Main PCB Assembly Kit, P/N 230226.999.000
6 Screw, Main PCB Cover Short 2
7 Screw, Main PCB Cover Long 1
8 Main PCB 1
9 Screw, Main PCB Retaining Screw 1
Kit 11: User Interface Board Kit, P/N 230227.999.000
24 Screw, User Interface to Housing 3
25 User Interface Board 1
26 O-ring, User Interface Board 1
Kit 13: Position Feedback Potentiometer Kit, P/N 199794.999.000
49 Screw, Feedback Potentiometer to Housing 2
50 Metal Washer 2
51 Position Feedback Potentiometer 1
Table XII: Spare Parts Kits (continued)
12 Logix 3400MD Mounting Kits
12.1 Valtek Mounting Kits
Table XIII: Valtek Linear Mounting Kits
Spud
25 in
2
50 in
2
* 100-200 in
2
Standard Handwheel Standard Handwheel Standard Handwheel
2.00 164432 164433 164434 164433
2.62 164435 164436 **164437** 164436
2.88 164437 164438
3.38 164439 164440
4.75 164439 164440
* A 50 square", 2.00 spud with live loading requires kit number. ** Live-loading is not available on a 100 in
2
, 2.62 spud.
Table XIV: Valtork Rotary Mounting Kits*
Spud
25 in
2
50 in
2
* 100-200 in
2
Standard Optional Standard Optional Standard Optional
0.44 135429 135432 135430 135431
0.63 135429 135437 135430 135433 135431
0.75 135429 135438 135430 137212 135431
0.88 135429 135439 135430 137213 135431 135434
1.12 135429 135430 137214 135431 137215
1.50 135429 135430 135431 137216
1.75 135429 135430 135431 137217
* Standard: All rotary valves with standard accessories (end of shaft mount). Optional: All rotary valves with handwheels or volume tanks (linkage design).
