Logix 3400MD Digital Positioner FCD LGENIM3404-00 – 9/09
30
Fieldbus
Block
Index
Fieldbus Variable
Name
Transducer
Block
Fieldbus
Datatypes
Logix Positioner
R/W Description
Register Type
Fix
Pt
Rd
Variable Name
83 VALVE_TRIMNO XDTB_MAIN UNSIGNED 8 222 U_CHAR NO VALVEtrimno NRW User Info, Valve, Trim Diameter
84 VALVE_SN XDTB_MAIN VISIBLE_
STRING
223 STRING NO VALVEsn NRW User Info, Vlave, Serial Number
85 STEM_DIAM XDTB_MAIN FLOAT 224 FLOAT NO STEMdiam NRW User Info, Vlave, Stem/Shaft
Diameter
86 RATED_TRAVEL XDTB_MAIN FLOAT 225 FLOAT NO RATEDtrav NRW User Info, Valve, Rated Travel
87 INLET_PRESS XDTB_MAIN FLOAT 226 FLOAT NO INLETpress NRW User Info, Valve, Upstream
Pressure
88 OUTLET_PRESS XDTB_MAIN FLOAT 227 FLOAT NO OUTLETpress NRW User Info, Valve, Downstream
Pressure
89 ACT_MAN_ID XDTB_MAIN UNSIGNED 8 228 U_CHAR NO ACTman NRW User Info, Actuator,
Manufacturer
90 ACT_FAIL_ACTION XDTB_MAIN UNSIGNED 8 N/A N/A N/A N/A NRW For Future Use
91 ACT_MODEL_NUM XDTB_MAIN VISIBLE_
STRING
N/A N/A N/A N/A NRW For Future Use
92 ACT_SN XDTB_MAIN VISIBLE_
STRING
231 U_CHAR NO ACTsn NRW User Info, Actuator Serial
Number
93 ACT_TYPE XDTB_MAIN UNSIGNED 8 232 U_CHAR NO ACTtype NRW User Info, Actuator, Type
94 ACT_SIZE XDTB_MAIN UNSIGNED 8 233 U_CHAR NO ACTsize NRW User Info, Actuator, Size
95 ACT_AREA XDTB_MAIN FLOAT 209 U_INT /10 ACTarea NRW Actuator Area
96 SPRING_TYPE XDTB_MAIN UNSIGNED 8 234 U_CHAR NO SPRINGtype NRW User Info, Actuator, Spring
Type: single, dual, etc.
97 PO_DATE XDTB_MAIN VISIBLE_
STRING
235 STRING NO PO_date NRW User Info, Purchase Order Date
98 INSTALL_DATE XDTB_MAIN VISIBLE_
STRING
236 STRING NO INSTALL_date NRW User Info, Install Date
71 VALVE_MODEL_NUM XDTB_MAIN VISIBLE_
STRING
N/A N/A N/A N/A NRW User Info, Valve Model Number
99 MFG_PHONE XDTB_MAIN VISIBLE_
STRING
N/A N/A N/A N/A NRW User Info, Manufacturer Phone
Number
100 PUR_ORDER_NUM XDTB_MAIN VISIBLE_
STRING
N/A N/A N/A N/A NRW User Info, Purchase Order
Number
102 XD_CAL_LOC XDTB_MAIN VISIBLE_
STRING
N/A N/A N/A N/A SRW User Info, Calibration Location
104 XD_CAL_WHO XDTB_MAIN VISIBLE_
STRING
N/A N/A N/A N/A SRW User Info, Calibration done by
Devide Mode and Status Parameters
13 DIAGNOSTICS_LEVEL XDTB_MD UNSIGNED 8 258 U_CHAR NO LD_MD_MODE R Is this an LD or an MD Device
16 CONTROLLER_STATE_
STATUS
XDTB_MAIN BIT_STRING 260 U_CHAR NO Mode_Status R Status, Alarm, Mode Flags
18 POSITIONER_STATUS XDTB_MAIN BIT_STRING 261 U_CHAR NO Positioner_
Status
R Status, Alarm, Positioner Flags
14 MECHANICAL_STATUS XDTB_MD BIT_STRING 262 U_CHAR NO Mechanical_
Status
R Status, Alarm, Mechanical Flags
