User Instructions - Logix® 520MD+ Series Digital Positioner
FCD LGENIM0105-00
© Flowserve Corporation 42 Field Trial Version – Printed October 28, 2011
17.2 Status Code Index
Table 22: Status Code Index
Description Status Code
A/O Cal in Prog GRGY
A/O Range Small RGYR
Actuation Ratio WRN YYYY
Actuator Cycles WRN YGGY
Actuator Travel WRN YGGY
Air Supply Humid WRN YYRY
Air Supply Icing WRN YYRR
Analog In < ADC Range RGGG
Analog In > ADC Range RGGG
Analog In Cal Error RGGG
Analog In Cal in Prog GRGY
Analog In Range Small RGGG
Backlash ALM RRYY
Backlash WRN YRYY
Bellows Cycles WRN YGGY
Bellows Travel WRN YGGY
Calibration in Progress GRGY
Card 1 Error RYYR
Card 1 Fail WRN RYYR
Card 1 No Loop Pwr RYYR
Card 1 WRN RYYR
Card 2 Error RYYY
Card 2 Fail WRN RYYY
Card 2 No Loop Pwr RYYY
Card 2 WRN RYYY
Closed Too Far WRN YYGY
Cmd Amplitude ALM RYGY
Cmd Amplitude WRN YGYR
Cmd Control ALM RYGY
Cmd Control WRN YGYR
Cmd Frequency ALM RYGY
Cmd Frequency WRN YGYR
CST Failed WRN YGRY
DI Cmd Override GRGR
Digital Cmd Mode GGYY
Driver Module ALM RRYR
Factory Reset State RGRR
Feedback Cal Change RGRY
Feedback Cal Error RGGY
Friction Cal in Prog GRGY
Friction Cal Req GYYY
Friction High ALM RRGR
Friction High WRN YRGR
Friction Low ALM RRGY
Friction Low WRN YRGY
ILO Time Out RGGR
Initializing GGYR
Jog Cal Set 100% Pos GRRR
Jog Cmd Mode GRRY
Local Interface Off GGYG
Low Battery WRN YRRG
Main Board Fail WRN RYRR
Memory Error WRN YYYR
No Motion Time Out RGYY
Opened Too Far WRN YYGY
Piezo Volts ALM RRRY
Piezo Volts High ALM RRRY
Piezo Volts High WRN YRRY
Piezo Volts Low ALM RRRY
Piezo Volts Low WRN YRRY
Piezo Volts WRN YRRY
Pilot Cycles WRN YGGY
Pilot Response ALM RRGG
Pilot Response WRN YRGG
Pilot Travel WRN YGGY
Pneumatic Leak WRN YRYR
Position < ADC Range RGGY
Position > ADC Range RGGY
Position Limit Alert YGGG
Position Range Small RGGY
Position Shift WRN YYGY
Power ON GGGG
Press Board Fail WRN RYRY
Pressure Cal in Prog GRGY
Pressure Cal Req GYYG
Psn Amplitude ALM RYGR
Psn Amplitude WRN YGYY
Psn Control ALM RYGR
Psn Control WRN YGYY
Psn Deviation ALM RRRR
Psn Frequency ALM RYGR
Psn Frequency WRN YGYY
Psn High Limit Alert YGGG
Psn Low Limit Alert YGGG
Psn Sensor Fail ALM RYRG
PST Failed WRN YGRR
PST Scheduled GYYR
Setting ILO GRGY
Settle Time Out RGYG
Signature or PST GRGG
Soft Stop Alert GYGY
Soft Stop High Alert GYGY
Soft Stop Low Alert GYGY
Software Error WRN YYRG
Spring Fail WRN YRRR
Squawk Mode GGRR
Stiction ALM RRYG
Stiction WRN YRYG
Stroke Cal in Prog GRGY
Stroke Cal Req RGRG
Stroke Shift RGRY
Stroke Span Decrease RGRY
Stroke Span Increase RGRY
Supply Press Hi WRN YYGR
Supply Press Lo ALM RYYG
Supply Press Lo WRN YYYG
Temperature High WRN YYGG
Temperature Low WRN YYGG
Temperature WRN YYGG
Tight Shut Off Mode GGGY
Valve Can't Move ALM RYGG
Valve Can't Open ALM RYGG
Valve Can't Shut ALM RYGG
Valve Cycles WRN YGGY
Valve Cycles WRN YGGY
Valve Travel WRN YGGY
