Flowserve Logix 520MD Plus Series User Manual

User Instructions - Logix® 520MD+ Series Digital Positioner
FCD LGENIM0105-00
© Flowserve Corporation 54 Field Trial Version – Printed October 28, 2011
19.2 Spare Parts Kits
Table 24: Spare Parts Kits
Ref.
Description Part-no.
1
2
3
Cover:
Yellow
Black
White
283450.999.000
283451.999.000
283452.999.000
4
5
6
7
8
Boards:
Main
LCD
Pressure Sensor
Multi-Function Card
Safety Discrete Output Card
283453.999.000
283454.999.000
283455.999.000
283456.999.000
283457.999.000
9
10
Pilot Relay Module:
Single Acting (Poppet)
Double or Single Acting (Spool)
283458.999.000
283459.999.000
11
12
13
14
15
16
Switches:
Mechanical Switch
Reed Switch
P&F SJ2-SN
P&F SJ2-S1N
P&F NJ2-V3-N
P&F NBB2-V3-E2 (2-wire configuration)
TBD
TBD
TBD
TBD
TBD
TBD
19.3 Mounting Kits
Table 25: Mounting Kits
Description Part-no.
IEC 534 part 6
(FloTop, Kämmer KA, Kämmer
KP, and standard
NAMUR linear valves)
213619.999.000
Rotary VDI/VDE 3845
(DIN ISO 5211)
188151.999.000
Flowserve direct mounting 214004.999.000
Linear VDI / VDE 3847 255242.999.000
Figure 33: Spare Parts Kits
1 - 3
6
9, 10
5
7, 8
4
11 - 16
