Flowserve Logix 520MD Series User Manual

11
®
User Instructions Logix 520MD - LGENIM0520-01 11/09
4 - 20 IN
Position Feedback
Current Loop
(Logix Output)
Position Command
Current Loop
(Logix Input)
CAUTION: Isolated Power Sources Required.
12 VDC
to 40 VDC
Spannungs-
quelle
4 to 20 mA
Current Source
+
+
–
–
4 - 20 OUT
+11 -12 +31 -32
Figure 6: 4-20 mA Analog Output BoardFigure 5: Analog Output Board Power

Flowserve Logix 520MD Series Specifications

General

Brand	Flowserve
Model	Logix 520MD Series
Category	Valve Positioners
Language	English
