Flowserve Logix 520MD Series User Manual

18
®
User Instructions Logix 520MD - LGENIM0520-01 11/09
Figure 10: Dimensional Drawing for the Logix 520MD Series Digital Positioner
3.9
98.14
LED WINDOW
FRONT VIEW
BACK VIEW
"D" SHAFT OPTION
(STANDARD)
6.85
174.10
3.94
100.00
2.25
57.20
2.25
57.20
2.52
64.10
2.09
53.00
1.13
28.60
1.13
28.60
.70
17.70
1.39
35.40
1.39
35.40
.70
17.70
M8X1,25 OR 5/16"-18UNC
M6
G1/4" OR
1/4" NPT
M20X1,5 OR
1/2" NPT
EXTERIOR
GROUNDING
SCREW
.90
22.95
.39
10.00
.09
2.31
1.3
32.00
.4
10.00
.2
4.00
.2
4.00
.2
4.80
"N" SHAFT OPTION
(VDI/VDE 3845, NAMUR)
M8
INCH
MM
