COMMUNICATION
Function Reading display information, reading/writing all configuration settings, and data log extraction
Type CB Modbus ASCII/RTU - RS232
Type CH Modbus ASCII/RTU - RS485 2-wire, bus termination without resistor for low power solutions
Type CX No communication, remote configuration possible with accessory cable (ACE02)
Speed (baud) 1200 - 2400 - 4800 - 9600 - 9600HP - 19200 – 38400
Addressing Maximum 247 addresses
A.4 OPERATIONAL
TOTAL
Digits 7 digits
Unit L, m3, US gal, igal, cf, Oil bbl, kg, ton, US ton, lb or none
Decimals 0 – 1 – 2 or 3
Note Total can be reset to zero
ACCUMULATED TOTAL
Digits 11 digits
Unit decimals According to selection for total
Note Accumulated total cannot be reset to zero
FLOW RATE
Digits 7 digits
Bar graph
speedometer
20 blocks, each block is 5% of total span
Decimals 0 – 1 - 2 or 3
Time units /sec - /min - /hr - /day
A.5 STANDARDS AND APPROVALS
APPLICABLE DIRECTIVES, LEGISLATION AND STANDARDS
EU Directives See Section E: Legal information[»74]
EMC FCC 47 CFR part 15
CSA CSA 22.2 No. 25, CSA 22.2 No. 30, CAN/CSA 22.2 No. 94-M91, CSA C22.2 No. 61010-1-12
FM FM3600; FM3615; FM3616; FM3810
IP & TYPE EN 60529; NEMA 250
HAZARDOUS AREA CLASSIFICATION
ATEX Certificate: DEKRA 14ATEX0006
Gas: II 2 G Ex d IIC T6 Gb
Dust: II 2 D Ex tb IIIC T85°C Db X
IECEx Certificate: IECEx DEK 14.0001X
Gas: Ex d IIC T6 Gb
Dust: Ex tb IIIC T85°C Db
CSA c-us Certificate: CSA.15.70010647
Explosionproof: Class I, Division 1, Groups A, B, C, D
Dust-Ignitionproof: Class II/III, Division 1, Groups E, F, G
Flameproof: Class I, Zone 1, AEx d IIC T6 Gb
Dust ignition protection by enclosure: Zone 21, AEx tb IIIC T85°C Db
FM Certificate: FM20US0082X
Project ID: 3054369
Explosionproof: Class I, Division 1, Groups A, B, C, D
Dust-Ignitionproof: Class II/III, Division 1, Groups E, F, G
Flameproof: Zone 1, AEx d IIC T6 Gb
Dust ignition protection by enclosure: Zone 21, AEx tb IIIC T85°C Db
