E119-P
FW_E119-P_M_v0301-02_EN Page 39
6.2 HANDLING THE E-SERIES ENCLOSURE
6.2.1 MAIN PARTS
2
3
6
7
1
5
4
Fig.18: Exploded view
1. Cover 5. Body
2. Main Electronics Module (MEM) 6. Grounding terminal
3. Battery 7. Label
4. Supply Module (RSM or BSM)
BSM
RSM
MEM
1
1
2
2
2
2
3
5
5
4
6
Fig.19: Main Electronic Module and two types of Supply Module (BSM, RSM)
1. Flatcable connector 4. Sensor supply voltage selection switches
2. Terminal connectors 5. Battery connector
3. PC configuration / communication connector 6. Battery
