APPENDIX D - REMOTE CONFIGURATION TOOL
D.1 INTRODUCTION
The free PC software can be downloaded and installed onto your computer system. The software
package allows you to set the configurations as desired, up- or download the settings to the MEM
and print a hardcopy for each product. With the software, programming of multiple products can be
done very easy.
D.2 CABLE CONNECTION
Before opening the enclosure, consult Section 6.2.3: Opening, assembling and closing the unit[»42].
To connect the MEM to a PC, a cable suitable for the supplied type of communication (CB, CH, CU,
CX) should be used, as illustrated in the following image:
CONFIG
USB
MINI
USB
USB
USB
USB
CH: R
S485
CX: service connector
ACE02
ACE06
ACE07
ACE01
CB: R
S232
CU: USB
Accessory:
Fig.43: Cable connection between MEM and PC.
