Fluidwell F103 WP User Manual

Page 47
FW-F103-P-XN-M_v2002_03_EN.docx
TECHNICAL SPECIFICATION
General
Display
Type
High intensity reflective numeric and alphanumeric LCD, UV-resistant.
Digits
Seven 17mm (0.67") and eleven 8mm (0.31"). Various symbols and measuring units.
Refresh rate
User definable: 8 times/sec - 30 secs.
Type ZB
LCD with LED backlight. Improved readability in full sunlight and darkness.
Enclosures
General
Control Keys
Painting
Die-cast aluminum, Stainless Steel or GRP (Glassfibre Reinforced Polyamide) enclosure with
Polycarbonate window, silicone and EPDM gaskets. UV stabilized and flame retardant
material.
Three industrial micro-switch keys. UV-stabilized silicone keypad.
Aluminum enclosure only: UV-resistant 2-component industrial painting.
Field/wall-mount enclosures
Classification
Material and drillings
Aluminum
Aluminum extended back
Stainless Steel
Plastic
with conduit hub entries
Dimensions: 130 x 120 x 75mm (5.10” x 4.72” x 2.95”) – LxHxD.
TYPE 4(X)
Type HA, HL … HZ and HAA … HAZ
Type HBA … HBZ
SS 316 L, Type HAS … HSZ
HGA … HGZ
HGL: 2x 1/2" conduit hub entries – fitted with internal earthing plate
HGT: 1x 1/2" conduit hub entry – fitted with internal earthing plate
Operating temperature
Operational
-40°C to +70°C (-40°F to +158°F)
Relative humidity
90%, no condensation allowed.
Power supply
Type PB
Lithium battery - life-time depends upon settings - up to 5 years.
Type PX
6-30V DC; Power consumption max. 0.4 Watt.
Type PX-ZB
8-30V DC; Power consumption max. 1.0 Watt.
Sensor excitation
Type PB / PX
3V DC for low power pulse signals and 1.2V DC for coil pick-up.
Data protection
Type
EEPROM backup of all setting. Backup of running totals every minute.
Data retention at least 10 years.
Password
Configuration settings can be password protected.
Hazardous area
Class I, Division 2
Groups A-D, T5
CSA C22.2 No. 213-17
ANSI/UL 121201-2019
Directives and Standards
EMC
EN 61326-1; FCC 47 CFR part 15
LVD
CAN/CSA C22.2 No. 61010-1-12, UPD1:2015, UPD2:2016, AMD1:2018
UL 61010-1-12, AMD1:2018
RoHS
EN 50581
IP & TYPE
CSA C22.2 No. 94.2-15
UL 50E-2015
Terminals
Type
Torque
Minimum number of poles
Wire sizes
Replacements
PTR AKZ1550/__-3.81-GREEN
0.25 Nm
Only connectors with a minimum of 5 connected poles are allowed.
Solid: 0.14…1.5 mm
2
/ Stranded: 0.14…1.5 mm
2
/ Stranded with Ferrule: 0.25…1.0 mm
2
For suitable replacement connectors (cable part), please contact your supplier.
