3.3 CONFIGURATION SETTINGS
All settings of the F103-P can be set via the control panel. As an alternative, you can also use the
Remote Configuration Software which you can find on our website or through your supplier.
Depending on the type of communication interface your device has, you might need a specific
communication cable, which is available through your supplier.
3.3.1 OVERVIEW FUNCTIONS SETUP-LEVEL
1
TOTAL
1.1
UNIT
L – m3 – US gal – I gal – cf – oil bbl – kg – ton – US ton – lb – nL –
nm3 – (none)
1.2
DECIMALS
0 – 0.1 – 0.02 – 0.003
1.3
K-FACTOR
AUTO, 0.000010 – 9999999
1.4
FACTOR-X
x1 – x1000
1.5
CLEAR PASSWORD
000 – 999
1.6
CONTRACT HOUR
00:00 (24h format)
1.7
CURRENT DAY TOTAL
xxxxxxx
1.8
PREVIOUS DAY TOTAL
xxxxxxx
2
FLOWRATE
2.1
UNIT
mL – L – m3 – mg – g – kg – ton – US ton – US gal – I gal – Oil bbl –
lb – cf – rev – scf – nm3 – nL – p – (none)
2.2
TIME
/sec – /min – /hour – /day
2.3
DECIMALS
0 – 0.1 – 0.02 – 0.003
2.4
K-FACTOR
AUTO, 0.000010 – 9999999
2.5
CALCULATION
per 1 – 999 pulses
2.6
CUT-OFF
0.1 – 999.9 seconds
3
DISPLAY
3.1
FUNCTION
total – flowrate – acc. total
3.2
DAY TOTALS
off – operate – hidden
3.3
BACKLIGHT (brightness)
0% – 20% – 40% – 60% – 80% – 100%
4
POWERMAN
4.1
LCD NEW
fast – 1 sec – 3 sec – 15 sec – 30 sec – off
4.2
BATTERY MODE
operate - shelf
5
FLOWMETER
5.1
SIGNAL
NPN – NPN_LP – REED – REED_LP – PNP – PNP_LP – Coil_Hi –
Coil_Lo – Isolated Active Signal
5.2
UNITS
hand – auto-vol – auto-mas
5.3
UNIT
Auto-vol: L – m3 – US GAL – IGAL – cf – oil bbl
Auto mas: kg – ton – US ton – lb
5.4
K-FACTOR
0.000010 – 9999999
6
LINEARIZE
6.1
FREQ. / M-FACTOR 1
0000.1 – 9999.9 Hz / 0.000001 – 9.999999
6.2
FREQ. / M-FACTOR 2
0000.1 – 9999.9 Hz / 0.000001 – 9.999999
6.3
FREQ. / M-FACTOR n
0000.1 – 9999.9 Hz / 0.000001 – 9.999999
↕
↕
↕
6.F
FREQ. / M-FACTOR 15
0000.1 – 9999.9 Hz / 0.000001 – 9.999999
6.G
LINEARIZATION
enable – disable
6.H
DECIMALS FREQUENCY
0 – 0.1 – 0.02 – 0.003
