7
ANALOG
7.1
OUTPUT
enable – disable
7.2
RATE-MIN (4mA)
0000000 – 9999999
7.3
RATE-MAX (20mA)
0000000 – 9999999
7.4
CUT-OFF
0.0 – 9.9%
7.5
TUNE-MIN (4mA)
0000 – 9999
7.6
TUNE-MAX (20mA)
0000 – 9999
7.7
FILTER
1 – 99
8
PULSE
8.1
WIDTH
0.000 – 9.999 sec
8.2
SOLID STATE OUTPUT
enable – disable
8.3
AMOUNT
0000.000 – 9999999
9
COM-MODB
9.1
SPEED
1200 – 2400 – 4800 – 9600 – 9600HP – 19200 – 38400 - 57600
9.2
ADDRESS
001 – 247
9.3
MODE
off – bus asc – bus rtu
9.4
DATABITS
8 bits – 7 bits
9.5
PARITY
none – even – odd
For F103-P without data logging (without type -ZL)
10
OTHERS
10.1
MODEL
F103-P
10.2
SOFTWARE VERSION
xx.xx.xx
10.3
SERIAL NO
xxxxxxx
10.4
TIME
HH:MM:SS (24 hour format)
10.5
PASSWORD
0000 – 9999
10.6
QUICK SETUP
enable – disable
10.7
TAG NO
0000000 – 9999999
For F103-P with data logging (with type -ZL)
10
DATALOG
10.1
LOG INT
off – 1 min – 5 min – 10 min – 15 min – 30 min – 1 hr – 2 hr – 4 hr – 6
hr – 8 hr
10.2
DAILY LOG
off – single – dual
10.3
DAILY 1
00:00 – 23:59
10.4
DAILY 2
00:00 – 23:59
10.5
TIME
HH:MM:SS (24 hour format)
10.6
DATE
YY.MM.DD
11
OTHERS
11.1
MODEL
F103-P
11.2
SOFTWARE VERSION
xx.xx.xx
11.3
SERIAL NO
xxxxxxx
11.4
PASSWORD
0000 – 9999
11.5
QUICK SETUP
enable – disable
11.6
TAG NO
0000000 – 9999999
