Fluidwell F103 WP User Manual

Page 18
FW-F103-P-XN-M_v2002_03_EN.docx
3.3.2 EXPLANATION OF SETUP-MENU 1 – TOTAL
• First setup the flowmeter at SETUP MENU 5 - Flowmeter. It has a direct influence on the
settings for Total.
• Change of the type of flowmeter unit (SETUP 5.2 and SETUP 5.3) will cause the Total
unit to jump to the default setting of the new flowmeter unit type.
• When a different unit is selected, the actual total values are NOT recalculated!
1
TOTAL
1.1
UNIT
This setting determines the measurement unit for (accumulated) total
and the scaled pulse output. The measurement units which are
available, are controlled from the UNITS which are selected in the
flowmeter menu.
AUTO-VOL: L – m3 – US gal – I gal – cf – Oil bbl – nL – nm3
AUTO-MAS: kg – ton – US ton – lb
HAND: l – m3 – US gal – I gal – cf – Oil bbl – kg – ton –
US ton – lb – nL – nm3 – ---- (no unit)
1.2
DECIMALS
The decimal point determines for Total and accumulated Total the
number of digits following the decimal point.
The following can be selected:
0, 0.1, 0.02, 0.003
The next menu item can be modified only if the automatic unit
conversion in SETUP 5.2, Flowmeter-units, is set to Hand. Else,
the display will show “AUTO”.
1.3
K-FACTOR
With the Total K-Factor, the flowmeter pulse signals are converted to
a total unit. The Total K-Factor is based on the number of pulses
generated by the flowmeter per selected measurement unit
(SETUP 1.1). The more accurate the Total K-Factor, the more
accurate the functioning of the system will be.
After pressing PROG, the decimal point will be flashing. The decimal
position can be changed now by pressing the ▲-key.
1.4
FACTOR-X
This setting determines the multiplication factor of Total and
Accumulated Total and is also applicable to the Current and Previous
Day Totals. This functions allows to show 3 digits more of the Total /
accumulated Total. The amount shown is a rounded number. The
following can be selected:
x1 – x1000
When activated, the display will indicate an M on the display (e.g.
when combined with the unit CF it will indicate MCF).
1.5
CLEAR PASSWORD
Clearing Total by the Operator can be password protected.
This protection is disabled with value 000 (zero).
A 3 digit password can be programmed, for example 123.
1.6
CONTRACT HOUR
The contract hour can be set in steps of 1 hour to any hour of the day.
When the system clock reaches the time set in the contract hour, the
Current Day Total is copied to the Previous Day Total, after which the
measurement of the Current Day Total is restarted (reset to zero).
Without type ZL – Data logging, the clock will be interrupted in case
of a power-down. When the unit is powered up again, the display will
immediately ask the operator to enter the correct system time.
Without an initialized clock, all measurements and calculations are
performed as normal. However, when the Daily Total feature is
enabled, the detection of contract hour and updating the Current and
Previous Day Totals will not be done at the correct time.
1.7
CURRENT DAY-TOTAL
This setting shows the amount of product totalized, since the last
contract hour. This a ‘running’ totalizer and cannot be reset to zero.
1.8
PREVIOUS DAY-TOTAL
This setting shows the amount of product totalized, before the last
contract hour. This totalizer cannot be reset to zero.
See chapter 2 for information on reviewing more historical day totals.
