Linearization
The linearization table is an INDEXED variable. Reading and writing the entries of the linearization table is done by first selecting the
entry through the index. Valid values for the index are 0…14, which correspond with the linearization table entries 1 through 15.
Indexes outside this range will result in an error being sent back.
(See the communication-section of this appendix for setting the index and its extended functionality through variable 150 and 149).
PDU
ADDRESS
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 1024
[h] 0x400
41025
linearization
table entry
3
INDEXED
variable
R/W
struct
2x
uint24
The 3 registers represent a structure containing 2 variables
of each 3 bytes. The three least significant bytes (PDU
address 1024 and LSB of PDU address 1025) contain the
frequency part, the three most significant bytes (MSB of
PDU address 1025 and PDU address 1026) contain the M-
factor part.
Valid range for the frequency is 0.000 to 9999Hz. Decimal
point dependent on variable 1039. A value of 0 for frequency
means that entry is disabled.
Valid range for the M-factor 0.000000 to 9.999999.
[d] 1038
[h] 0x40E
41039
linearization
on/off
1
R/W
uint16
0=disable
1=enable
[d] 1039
[h] 0x40F
41040
decimals
1
R/W
uint16
0…3
This variable selects the number of decimals used for the
frequencies entered in the linearization table.
Analog output
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 112
[h] 0x070
40113
analog
output
1
R/W
uint16
0=disable
1=enable
[d] 113
[h] 0x071
40114
minimum
rate
2
R/W
uint32
0…9999999
Representation: unit, time, decimals depending on variables
48, 49, 50
[d] 116
[h] 0x074
40117
maximum
rate
2
R/W
uint32
0…9999999
Representation: unit, time, decimals depending on variables
48, 49, 50
[d] 119
[h] 0x077
40120
cut off
percentage
1
R/W
uint16
0...99
Representation: 0.0 – 9.9%
[d] 120
[h] 0x078
40121
tune
minimum
output
1
R/W
uint16
0...9999
[d] 122
[h] 0x07A
40123
tune
maximum
output
1
R/W
uInt16
0...9999
[d] 127
[h] 0x07F
40128
filter
1
R/W
uint16
1...99
Pulse output
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 128
[h] 0x080
40129
pulse time
width
1
R/W
uint16
0…9999
Representation: 0.001 – 9.999 sec
[d] 2152
[h] 0x868
402153
solid state
output
1
R/W
uint16
0=disable
1=enable
[d] 130
[h] 0x082
40131
pulse per X
quantity
2
R/W
uint32
1...9999999
Representation: 0.000001…9999999
depending on variables 133
[d] 133
[h] 0x085
40134
pulse
quantity
decimals
1
R/W
uint16
0…3
