Fluidwell F103 WP User Manual

Page 54
FW-F103-P-XN-M_v2002_03_EN.docx
[d] 2208
[h] 0x8A0
42209
Current day
total
4
R
unit64
0.000…9999999999
Representation: unit, decimals depending on variables 32,
33
[d] 2216
[h] 0x8A8
42217
Previous
day total
4
R
uint64
0.000…9999999999
Representation: unit, decimals depending on variables 32,
33
Flowrate
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 48
[h] 0x030
40049
unit
1
R/W
uint16
0=none
1=mL
2=L
3=m
3
4=US GAL
5=I GAL
6=CF
7=OilBBL
8=nL
9=nm
3
10=SCF
11=mg
12=g
13=kg
14=ton
15=lb
16=US ton
17=rev
18=P
[d] 49
[h] 0x031
40050
time unit
1
R/W
uint16
0=/sec
1=/min
2=/hour
3=/day
[d] 50
[h] 0x032
40051
decimals
1
R/W
uint16
0…3
[d] 51
[h] 0x033
40052
K-factor
2
R/W
uint32
1...9999999
Representation: 0.000010…9999999
depending on variable 54: decimals K-factor.
[d] 54
[h] 0x036
40055
K-factor
decimals
1
R/W
uint16
0…6
[d] 55
[h] 0x037
40056
calculation
nr of pulses
1
R/W
uint16
1...255
[d] 56
[h] 0x038
40057
cut-off time
1
R/W
uint16
1...9999
Representation: 0.0001 – 9.999 sec
Display
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 64
[h] 0x040
40065
display
function
1
R/W
uint16
0=total
1=flowrate
2=acc.total
[d] 2147
[h] 0x863
42148
day totals
1
R/W
uint16
0=hidden
1=operate
2=off
[d] 80
[h] 0x050
40081
LCD update
time
1
R/W
uint16
0= fast
1=1 sec
2=3 sec
3=15 sec
4=30 sec
5=off
[d] 67
[h] 0x043
40068
backlight
brightness
1
R/W
uint16
0=off
1=20%
2=40%
3=60%
4=80%
5=100%
Flowmeter
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 96
[h] 0x060
40097
flowmeter
signal
1
R/W
uint16
0=NPN
1=NPN LP
2=Reed
3=Reed LP
4=PNP
5=PNP LP
6=NAMUR
7=coil hi
8= coil lo
9=act 8.2V
10=act 24V
[d] 1051
[h] 0x41B
41052
K-factor -
unit type
1
R/W
uint16
0=Hand
1=Volumetric
2=Mass
[d] 1050
[h] 0x41A
41051
K-factor -
unit
1
R/W
uint16
0=none
1=L
2= m
3
3=US GAL
4= I GAL
5=CF
6= OilBBL
7=kg
8=ton
9=lb
10=us ton
[d] 1046
[h] 0x416
41047
K-factor
2
R/W
uint32
1...9999999
Representation: 0.000010…9999999
depending on variable 54: decimals K-factor.
[d] 1049
[h] 0x419
41050
K-factor
decimals
1
R/W
uint16
0…6
