Fluidwell F103 WP User Manual

Page 53
FW-F103-P-XN-M_v2002_03_EN.docx
Historical previous day totals of the F103-P – Integer based – Contiguous read
The read-out of historical previous day totals is done via 2 INDEXED variables containing the number of decimals and the value.
These 2 variables can be read as one contiguous list of 3 registers (in a single read action).
Reading is done by first selecting the right entry (day) through the index. Valid values for the index are 0…14, which correspond with
the previous day totals of 1 day old through 15 days old. Indexes outside this range will result in an error being sent back.
(See the communication-section of this appendix for setting the index and its extended functionality through variable 150 and 149).
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 5888
[h] 0x1700
45889
Previous day total
decimals
1
INDEXED
variable
R
unit8
0…3
[d] 5889
[h] 0x1701
45890
Previous day total
2
INDEXED
variable
R
uint64
0.000…9999999999
Representation: unit depends on variable 32,
decimals depends on variables 5888 (0x1700)
Runtime variables of the F103-P – Floating point based 32 bit
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 6402
[h] 0x1902
46403
total
2
R
float32
0…9999999
Representation: unit depending on variable 32
[d] 6404
[h] 0x1904
46405
accumulated total
2
R
float32
0…99999999999
Representation: unit depending on variable 32
[d] 6406
[h] 0x1906
46407
flow rate
2
R
float32
0…9999999
Representation: unit and time depending on
variables 48, 49
[d] 6408
[h] 0x1908
46409
current day total
2
R
float32
0…9999999
Representation: unit depends on variable 32
[d] 6410
[h] 0x190A
46411
previous day total
2
R
float32
0…9999999
Representation: unit depends on variable 32
Note: The list of runtime variables shown above can be read as one contiguous list of registers. Unused registers return 0.
Runtime variables of the F103-P – Floating point based 64 bit
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 6656
[h] 0x1A00
46657
total
4
R
float64
0…9999999
Representation: unit depending on variable 32
[d] 6660
[h] 0x1A04
46661
accumulated total
4
R
float64
0…99999999999
Representation: unit depending on variable 32
[d] 6664
[h] 0x1A08
46665
current day total
4
R
float64
0…9999999
Representation: unit depends on variable 32
[d] 6668
[h] 0x1A0C
46669
previous day total
4
R
float64
0…9999999
Representation: unit depends on variable 32
Note: The list of runtime variables shown above can be read as one contiguous list of registers. Unused registers return 0.
Configuration variables of the F103-P
Total
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 32
[h] 0x020
40033
unit
1
R/W
uint16
0=none
1=L
2= m3
3=US GAL
4= I GAL
5=CF
6= OilBBL
7=kg
8=ton
9=lb
10=us ton
11=nL
12=nm3
[d] 33
[h] 0x021
40034
decimals
1
R/W
uint16
0…3
[d] 34
[h] 0x022
40035
K-factor
2
R/W
uint32
1...9999999
Representation: 0.000010…9999999 depending on
variable 37: decimals K-factor.
[d] 37
[h] 0x025
40038
K-factor
decimals
1
R/W
uint16
0…6
[d] 47
[h] 0x02F
40048
multiply
factor
1
R/W
uint16
0=x1
3=x1000
[d] 1052
[h] 0x41C
41053
clear total
password
1
R/W
unit16
000 … 999
Setting 000 disables the clear total password feature.
[d] 2146
[h] 0x862
42147
contract
hour
1
R/W
uint16
0…23 Hour
