Fluidwell F103 WP User Manual

Page 52
FW-F103-P-XN-M_v2002_03_EN.docx
Runtime variables of the F103-P
Reading flow rate, total, accumulated total or current day totals: When reading runtime variables, the
given value may differ slightly from the value that is displayed on the display – this is due to the fact
that the display is limited in the number of digits and may have a slower update rate.
When variables are read in integer format, the returned values are given including the decimals. For
example, when two decimals are selected for total and total has a value of 123456.78 the display will
show 23456.78 while communication will read a “total” of 12345678 (note that the decimals should
be adapted according the setting in “total decimals” which is in this case 2).
Runtime variables of the F103-P – Integer based – Individual read
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 255
[h] 0x00FF
40256
battery status
1
R
unit16
0 = unknown
1 = normal
2 = low battery
[d] 516
[h] 0x0204
40517
error status (bitfield)
1
R
uint16
[d] 0 = no error
[d] 1 = display error
[d] 2 = data-storage error
[d] 4 = initialization error
[d] 8 = data-storage error data logging (option ZL)
[d] 64 = Linearization error (M-factor out of range)
[d] 128 = Automatic K-factor conversion error
[d] 560
[h] 0x0230
40561
accumulated total
3
R
uint48
0.000…99999999999999
Representation: unit, decimals depending on
variables 32, 33
[d] 566
[h] 0x0236
40567
total
3
R *
uint48
0.000…9999999999
Representation: unit, decimals depending on
variables 32, 33
[d] 572
[h] 0x023C
40573
flow rate
2
R
uint32
0.000…9999999
Representation: unit, time, decimals depending
on variables 48, 49, 50
[d] 4640
[h] 0x1220
44641
Total command
register
1
R/W
uint16
Commands:
0x0102: Clear total
* Clearing total: Total can also be cleared by writing the correct command to the total command register, as shown above.
It is also still possible to use the old method: Write a value of 0 to all the 3 registers of total in a single write action.
Writing any other value will result in the reply of an error message.
Note: The runtime variables shown in above list must always be read or written individually, for the indicated number of
registers, in 1 single action!
Runtime variables of the F103-P – Integer based – Contiguous read
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 6146
[h] 0x1802
46147
total
4
R
uint64
0.000…9999999999
Representation: unit, decimals depending on
variables 32, 33
[d] 6150
[h] 0x1806
46151
accumulated total
4
R
uint64
0.000…99999999999999
Representation: unit, decimals depending on
variables 32, 33
[d] 6154
[h] 0x180A
46155
flow rate
2
R
uint32
0.000…9999999
Representation: unit, time, decimals depending
on variables 48, 49, 50
[d] 6156
[h] 0x180C
46157
current day total
4
R
uint64
0.000…9999999999
Representation: unit, decimals depending on
variables 32, 33
[d] 6160
[h] 0x1810
46161
previous day total
4
R
uint64
0.000…9999999999
Representation: unit, decimals depending on
variables 32, 33
Note: The list of runtime variables shown above can be read as one contiguous list of registers. Unused registers return 0.
