Fluke Biomedical ProSim 2 - Page 50

Vital Signs Simulator
Remote Operation
37
Table 16. Blood Pressure Function Commands
Action
Command
Channel 1 Channel 2 Channel 3 Channel 4
BP sensitivity to 5 μV/V/mmHg BPSNS5
BP sensitivity to 40 μV/V/mmHg BPSNS40
Zero each channel P1S0 P2S0 P3S0 P4S0
Zero all channels ZALL
Static Pressure Levels
-5 mmHg static NA NA P3S-5 P4S-5
-10 mmHg static P1S-10 P2S-10 NA NA
20 mmHg static NA NA P3S20 P4S20
40 mmHg static NA NA P3S40 P4S40
50 mmHg static NA P2S50 NA NA
60 mmHg static NA NA P3S60 P4S60
80 mmHg static P1S80 NA P3S80 P4S80
100 mmHg static NA P2S100 P3S100 P4S100
150 mmHg static NA P2S150 NA NA
160 mmHg static P1S160 NA NA NA
200 mmHg static NA P2S200 NA NA
