ProSim™ 2/3
Users Manual
38
Table 16. Blood Pressure Function Commands (cont.)
Action
Command
Channel 1 Channel 2 Channel 3 Channel 4
Static Pressure Levels (cont.)
240 mmHg static P1S240 P2S240 NA NA
320 mmHg static P1S320 NA NA NA
400 mmHg static P1S400 NA NA NA
Dynamic Waveforms
Arterial at 120/80 P1ART P2ART P3ART NA
Radial at 120/80 P1RART P2RART P3RART NA
Left vent at 120/0 P1LV P2LV P3LV NA
Right vent at 25/0 P1RV P2RV P3RV P4RV
Pulmonary at 25/10 NA P2PA P3PA P4PA
Pulmonary at 10/2 NA P2W P3W P4W
Left atrium at 14/4 NA P2LA P3LA NA
Right atrium CVP at 15/10 NA P2CVP P3CVP P4CVP
