Product Familiarization
The manual explains features for multiple models. Because models have different features, not all of the
information in the manual may apply to your Meter. Use Table 1 to identify the features of your Meter.
Features
Table 1 is a list of the features for each Meter.
Table 1. Features
Switch
Position
Measurement Function 110 113 114 115 117
OFF The Meter is turned off.
x
Automatically selects ac or dc volts based on the sensed input
with a low impedance input.
e
AC voltage from 0.06 V to 600 V.
Frequency from 5 Hz to 100 kHz.
D
DC voltage from 0.001 V to 600 V.
l
AC voltage from 6.0 to 600 mV, dc-coupled.
DC voltage from 0.1 to 600 mV.
Ω Ohms from 0.1 Ω to 40 MΩ.
s Continuity beeper turns on at <20 Ω and turns off at >250 Ω.
k CHEK
LoZ low impedance measurement function to simultaneously
test for voltage or continuity.
R Diode Test. Displays OL above 2.0 V.
S Farads from 1 nF to 9999 μF.
j
AC current from 0.1 A to 10 A (>10 to 20 A, 30 seconds on,
10 minutes off). >10.00 A display flashes. >20 A, OL is
displayed. DC-coupled.
Frequency from 45 Hz to 5 kHz.
I
DC current from 0.001 A to 10 A (>10 A to 20 A, 30 seconds
on, 10 minutes off). >10.00 A display flashes. >20 A, OL is
displayed.
w
Non-contact sensing of ac voltage.
Note: All ac functions and Auto-V LoZ are true-rms. AC voltage is ac-coupled. Auto-V LoZ, AC mV and
AC amps are dc-coupled.
