True-rms Multimeter
Product Familiarization
5
Error Messages
Table 4 is a list of error messages for the Meter.
Battery Saver™ (Sleep Mode)
If the Meter is ON, but inactive and not connected to voltage for more than 20 minutes, the display goes blank to
save battery life.To use the Meter, press any button or turn the rotary switch. To disable the Sleep mode, see
Power-Up Options. The Sleep mode is always disabled in the MIN MAX AVG mode.
MIN MAX AVG Recording Mode
The MIN MAX AVG recording mode captures the minimum and maximum input values (ignoring overloads), and
calculates a running average of all readings. When the Meter detects a new high or low, the Meter beeps.
Note
Autoranging and Battery Saver™ are disabled in MIN MAX AVG mode.
1. Select the measurement function and range.
2. Push p to enter MIN MAX AVG mode.
M and MAX show on the display. The highest reading detected since entering MIN MAX AVG shows
on the display.
3. Push p to step through the low (MIN), average (AVG), and present readings.
4. To pause MIN MAX AVG recording without erasing stored values, push f. (K shows on the display.)
5. To resume MIN MAX AVG recording, push f again.
6. To exit and erase stored readings, push p for at least one second, or turn the rotary switch.
Table 4. Error Messages
Error Messages
bAtt Battery must be replaced before the Meter will operate.
CAL Err Calibration required. Meter calibration is required before the Meter will operate.
EEPr Err Internal error. The Meter must be repaired before it will operate.
F11- Err Internal error. The Meter must be repaired before it will operate.
