Fluke 112 User Manual

Models 110, 111 & 112
Users Manual
8
Testing for Continuity
aej06f.eps
Note
The continuity function works best as a fast, convenient
method to check for opens and shorts. For maximum
accuracy in making resistance measurements, use the
Meter’s resistance (e) function.
Testing Diodes
Forward Bias
Single Beep
Reverse Bias
Good Diode Good Diode
Shorted
and
Bad Diode
Open
Bad Diode
aej07f.eps

Fluke 112 Specifications

General

Category	Multimeter
Continuity	Yes
Diode Test	Yes
Display	Digital
DC Voltage Ranges	400.0 mV, 4.000 V, 40.00 V, 400.0 V, 600 V
Resistance Ranges	400.0 Ω, 4.000 kΩ, 40.00 kΩ, 400.0 kΩ, 4.000 MΩ, 40.00 MΩ
Safety Category	CAT III 600 V
AC Voltage Accuracy	±(1.0% + 3)
Battery Type	9 V
DC Voltage Accuracy	±(0.5% + 2 counts)
AC Voltage Ranges	4.000 V, 40.00 V, 400.0 V, 600 V
