Fluke 12 User Manual

12 Multimeter
Users Manual
26
Function Range Resolution Accuracy (50 to 400 Hz)
{
4000 mV* 1 mV ±(1.9 %+3)
4.000 V 0.001 V ±(1.9 %+3)
40.00 V 0.01 V ±(1.9 %+3)
400.0 V 0.1 V ±(1.9 %+3)
600 V 1 V ±(1.9 %+3)
E 4000 mV* 1 mV ±(0.9 %+2)
4.000 V 0.001 V ±(0.9 %+2)
40.00 V 0.01 V ±(0.9 %+1)
400.0 V 0.1 V ±(0.9 %+1)
600 V 1 V ±(0.9 %+1)
e 400.0 Ω 0.1 Ω ±(0.9 %+2)
4.000 kΩ 0.001 kΩ ±(0.9 %+l)
40.00 kΩ 0.01 kΩ ±(0.9 %+1)
400.0 kΩ 0.1 kΩ ±(0.9 %+1)
4.000 MΩ 0.001 MΩ ±(0.9 %+1)
40.00 MΩ 0.01 MΩ ±(1.5 %+3)
E 1.000 µF 0.001 µF ±(1.9 %+2)
10.00 µF 0.01 µF ±(1.9 %+2)
100.0 µF 0.1 µF ±(1.9 %+2)
10000 µF 1.0 µF ≤1000 µF ±(1.9 %+2)
>1000 µF ±(10 % + 90) Typical
MG
2.000 V 0.001 V ±(0.9 %+2) †
* The 4000 mV range can only be entered in manual range mode. Use the 4000 mV range with accessories.
† The beeper is guaranteed to come on at <25 Ω and turn off at >250 Ω. The meter detects opens or shorts of 250 µs or
longer.

Fluke 12 Specifications

General

Continuity Beeper	Yes
Diode Test	Yes
Safety Rating	CAT III 600 V
Operating Temperature	0 °C to 50 °C
Display Type	LCD
Voltage DC	600V
Voltage AC	600V
DC Current Range	10 A
AC Current Range	10 A
Resistance Range	40 MΩ
Battery Type	9V
Dimensions	169 mm x 84 mm x 44 mm
