Fluke 1630 User Manual

Earth Ground Clamp
Symbols
3
• CAT II equipment is designed to protect against
transients from energy-consuming equipment
supplied from the fixed installation, such as TVs,
PCs, portable tools, and other household
appliances.
• CAT III equipment is designed to protect against
transients in equipment in fixed-equipment
installations, such as distribution panels, feeders
and short branch circuits, and lighting systems in
large buildings.
• Use extreme caution when working around bare
conductors or busbars. Contact with the conductor
could result in electric shock.
• Use caution when working with voltages above 60 V dc
or 30 V ac. Such voltages pose a shock hazard.
Symbols
The following symbols are found on the Clamp or in this manual.
, May be used on hazardous live conductors
W Risk of danger. Important information. See Users Manual.
X Hazardous voltage. Risk of electric shock.
T Double insulation
M Battery
P Conforms to relevant European Union directives
~
Do not dispose of this product as unsorted municipal waste.
Contact Fluke or a qualified recycler for disposal.
) Complies with Canadian and US Standards

Fluke 1630 Specifications

General

Control type	Buttons
Housing color	Red, Black, Yellow
Maximum voltage	1000 V
Built-in display	Yes
Display technology	LCD
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Battery size	AA
Battery technology	Alkaline
Battery life (measurements)	15
Number of batteries supported	4

Weight and Dimensions

Depth	48 mm
Width	105 mm
Height	283 mm
Weight	880 g
