Power Logger
Before You Start
7
Magnet Hanger Kit
The accessory shown in Figure 2 is used to:
•
Hang the Logger with power supply attached (use two magnets)
•
Hang the Logger separately (use two magnets)
•
Hang the power supply separately (use one magnet)
Voltage Test Leads
Voltage test leads are four-core, flat, test leads that do not tangle and
can be installed in tight spaces. On installations where the access to
Neutral is out of reach with the three-phase test lead, use the black
test lead to extend the Neutral lead.
For single phase measurements use the red and black test leads.
Figure 2. Magnet Hanger Kit
