Power Logger
Function Selection Buttons
25
Topology (Distribution System)
Select the appropriate system. A connection diagram for the voltage
test leads and current sensors is shown on the Logger.
A diagram is also available with (Connection diagram) from the
Change Configuration menu. Examples of these diagrams are
shown on the following pages.
Single Phase
Example: Branch circuit at an outlet.
Energy Study
Load Study (no voltage measurement)
