5. Use the Thin-Flexi current probes and plug the phase
A current probe into the phase A/L1 input jack on the
logger, the phase B/L2 current probe into the phase
B/L2 input jack on the logger, and the phase C/L3
current probe into the phase C/L3 input jack on the
logger.
6. Apply the iFlex Probes to the wires in the electrical
panel. Make sure the arrow on the probe points to the
load.
7. Connect the voltage test leads to neutral, phase A/L1,
phase B/L2, and phase C/L3.
8. With all of the connections done, check that the
voltages for phases A/L1, B/L2, and C/L3 are as
expected.
9. Read the current measurements for phases A/L1,
B/L2, C/L3, and N.
10. Push Verify Connection to check and correct the
phase rotation, phase mapping, and polarity of current
probes.
Most installations use a clockwise rotation.
11. Push Live-Trend to display a chart of the last
7 minutes.
12. Push to determine the power values, especially
active power and power factor.
13. Push Live-Trend to display a chart of the last
7 minutes.
14. Push for 3 seconds to take a snapshot of the
measurements.
15. Push and change the default configuration with
Edit Setup.
Typical setup:
- 1 week duration
- 1 minute for average calculation interval
- 15 minutes for demand interval
16. Push Start Logging.
You can review the live data with or . Return
to the active logging session with . Once the
logging session is completed it is accessible in
Memory/Settings - Logging Sessions.
17. Review the logged data using the softkeys V, A, Hz, +,
Power, and Energy. See page 36 for more
information.
18. To transfer and analyze the data using the PC
software, attach the USB flash drive to the Logger and
copy the logging session and screenshot.
Note
You can also use the USB cable or the USB WiFi
dongle to transfer the measurement data.
