1736/1738
Users Manual
6
WiFi and WiFi/BLE-to-USB Adapter
The USB adapter enables the wireless connectivity of the
Logger:
• Connection to the Fluke Connect™ smartphone app
for easy asset management and data sharing.
• Data transfer to "Energy Analyze Plus" PC software.
• Remote control via Virtual Network Computing (VNC).
See Remote Control for more information about VNC.
• Display and store data of up to 2 modules of the Fluke
FC 3000 series together with the instrument data into
logging sessions (requires WiFi/BLE adapter feature,
available with firmware version 2.0).
To install the adapter (see Figure 2) in the Logger:
1. Remove the Power Supply.
2. Unscrew the four screws and remove the battery door.
3. Remove the battery.
4. Insert the WiFi/BLE adapter in the compartment with
the serial number pointing upwards.
5. Connect the WiFi/BLE adapter to the USB port by
sliding it gently to the right until the adapter snaps into
the USB socket of the Logger. About 3.5 mm (0.14 in.)
of the metal shield should be visible.
6. Insert the battery.
7. Fasten the battery door.
hcf069.eps
Figure 2. Adapter Installation
2
1
3
4
5
