Fluke 1736 User Manual

1736/1738
Users Manual
44
Phase Color/Phase Labels
The phase colors are configurable to match with the
connector panel decal. Five schemes are available:
A/L1 B/L2 C/L3 N
US black red blue white
Canada red black blue white
EU brown black grey blue
UK (old) red yellow blue black
China yellow green red blue
To change the phase color/phase labels:
1. Push .
2. Push  (Instrument Settings).
3. Push  to highlight Phases and push  or touch
Phases target.
4. Select one of the available schemes.
5. Push  to toggle the phase label between A-B-C
and L1-L2-L3.
6. Push  to confirm the selection.
Date/Time Zone
The logger stores the measurement data in universal time
coordinate (UTC) to ensure continuity in time and accounts
for time changes due to daylight saving time (DST).
To display the time stamps of the measurement data
correctly, it is required to set the time zone. The Logger
adjusts automatically to DST. For example, a 1-week
measurement started on 2-Nov-2013 8:00 am ends on
9-Nov-2013 08:00 am even though the clock was set back
on 3-Nov-2013 from 02:00 to 01:00.
To set the time zone:
1. Push .
2. Push  (Instrument Settings).
3. Push  to highlight Time Zone and push  or
touch Time Zone target.
4. Select the regions/continents.
5. Push .
6. Continue to select the country/city/time zone until the
time zone configuration is done and the Instrument
Settings menu shows.

Fluke 1736 Specifications

General

Product type	Three phase power measurement logger
Cable lock slot type	Kensington
International Protection (IP) code	IP50
Operating altitude	0 - 4000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Built-in display	Yes
Display diagonal	4.3 \
Touchscreen type	Resistive
Display resolution	480 x 272 pixels
Display technology	TFT
Efficiency	68.2 %
Battery life	4 h
Charging time	6 h
Battery voltage	3.7 V
Input frequency	50/60 Hz
Battery capacity	9.25 Wh
Power consumption (max)	50 VA
Battery life (power save mode)	5.5 h

Weight and Dimensions

Depth	55 mm
Width	198 mm
Height	167 mm
Weight	1100 g
Power adapter weight	400 g
Power supply dimensions (WxDxH)	130 x 45 x 130 mm
