Fluke 1736 User Manual

1736/1738
Users Manual
54
Calibration
As an additional service we offer the regular examination
and calibration of your Logger. The recommended
calibration cycle is 2 years.
More information about how to contact Fluke is on page 2.
Service and Parts
Replacement parts and accessories are listed in Table 7
and shown in Figure 12. To order parts and accessories,
see How to Contact Fluke.
Table 7. Replacement Parts
Ref.
Description Qty.
Fluke Part or
Model Number

Power Supply: 1736 1 4583625
Power Supply: 1738 1 4717789
 Battery Door 1 4388072
 Battery Pack, Li ion 3.7 V 2500 mAh 1 4146702
 USB Cable 1 4704200

Input Decal, country specific
(US, Canada, Europe/UK, UK/old, China)
1 see Figure 7 on page 15

Line Cord, country specific
(N. American, Europe, UK, Australia, Japan, India/S. Africa, Brazil)
1 see Figure 1 on page 5
 Test Leads 0.1 m Red/Black, 1000 V CAT III 1 set 4715389
 Test Leads 1.5 m Red/Black, 1000 V CAT III 1 set 4715392
 Color-coded Wire Clips 1 set 4394925

USB Flash Drive
(includes User Manuals and installer for PC software)
1 NA

Fluke 1736 Specifications

General

Product type	Three phase power measurement logger
Cable lock slot type	Kensington
International Protection (IP) code	IP50
Operating altitude	0 - 4000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Built-in display	Yes
Display diagonal	4.3 \
Touchscreen type	Resistive
Display resolution	480 x 272 pixels
Display technology	TFT
Efficiency	68.2 %
Battery life	4 h
Charging time	6 h
Battery voltage	3.7 V
Input frequency	50/60 Hz
Battery capacity	9.25 Wh
Power consumption (max)	50 VA
Battery life (power save mode)	5.5 h

Weight and Dimensions

Depth	55 mm
Width	198 mm
Height	167 mm
Weight	1100 g
Power adapter weight	400 g
Power supply dimensions (WxDxH)	130 x 45 x 130 mm
