Digital Multimeters
Specifications
21
Continuity Threshold
Frequency
[4]
(10 Hz to 100 kHz)
50.00 Hz
500.0 Hz
5.000 kHz
50.00 kHz
100.0 kHz
0.01 Hz
0.1 Hz
0.001 kHz
0.01 kHz
0.1 kHz
NA 0.1 % + 3
Duty Cycle
[4]
1 % to 99 % 0.1 % NA
1% typical
[5]
[1] Typically, open circuit test voltage is 2.0 V and short circuit current is <0.6 mA.
[2] Typical open circuit test voltage: 0.54 V. Maximum short circuit current: 1.8 mA.
[3] Specifications do not include errors due to test lead capacitance and capacitance floor (may be up to 1.5 nF in the 40 nF range).
[4] All ac, Hz, and duty cycle are specified from 1
% to 100 % of range. Input below 1 % of range are not specified.
[5] Typical means when the frequency is at 50 Hz or 60 Hz and the duty cycle is between 10
% and 90 %.
[6] Use type K thermocouple.
Function Range Resolution
Accuracy
15B MAX 17B MAX
Function Threshold
Continuity Threshold 70 Ω
