Fluke 28 II Ex - Rotary Switch Positions

28 II Ex
Getting Started
10
Table 3. Rotary Switch Positions
Switch Position
Function
Any Position When the Product is turned on, the Product model number briefly shows on the display.
J
AC voltage measurement
Push
 (yellow) for low-pass filter (K)
L DC voltage measurement
M
600 mV dc voltage range
Push  (yellow) for temperature ()
N Push E for continuity test.
e Resistance measurement
Push  (yellow) for capacitance measurement.
O Diode test
P
AC current measurements from 0 mA to 10.00 A
Push
 (yellow) for dc current measurements, from 0 mA to 10.00 A.
Q
AC current measurements from 0 μA to 6000 μA
Push
 (yellow) for dc current measurements from 0 μA to 6000 μA.
