Fluke 28 II Ex Getting Started

True-rms Digital Multimeter
Detailed Specifications
27
Detailed Specifications
For all detailed specifications:
Accuracy is specified for 2 years after calibration, at operating temperatures of 18 °C to 28 °C, with relative humidity at 0 % to 80 %.
Accuracy specifications take the form of ±([% of Reading] + [Number of least-significant digits]). In the 4 ½-digit mode, multiply the number of
least-significant digits (counts) by 10.
AC Voltage
AC conversions are ac-coupled and valid from 3 % to 100 % of range.
Range Resolution
Accuracy
45 – 65 Hz 30 – 200 Hz 200 – 440 Hz 440 Hz – 1 kHz 1 – 5 kHz 5 – 20 kHz
600.0 mV 0.1 mV
±(0.7 % + 4)
±(1.0 % + 4)
±(2 % + 4)
±(2 % + 20)
[1]
6.000 V 0.001 V
60.00 V 0.01 V
±(0.7 % + 2)
±(2 % + 4)
[2]
Unspecified
600.0 V 0.1 V Unspecified
1000 V 1 V Unspecified Unspecified
Low-Pass Filter
±(1.0 % + 4)
[1]
+1.0 % + 4
-6.0 % - 4
[3]
Unspecified Unspecified Unspecified
[1] Below 10 % of range, add 12 counts.
[2] Frequency range: 1 kHz to 2.5 kHz
[3] Specification increases from -1 % to -6 % at 440 Hz when filter is used.
Shop for Fluke products online at:
1.877.766.5412
www.MyFlukeStore.com

Fluke 28 II Ex Specifications

General

Diode test	Yes
Product type	Digital multimeter
Product color	Black, Red
Frequency range	0.0005 - 199.99 kHz
DC current range	0.0000001 - 10 A
DC voltage range	0.0001 - 1000 V
Resistance range	0.1 - 50000000 Ω
Measuring category	CAT IV 600V
Placement supported	Handheld multimeter
Basic accuracy (frequency)	0.005%
Basic accuracy (DC current)	0.2%
Basic accuracy (DC voltage)	0.05%
Temperature measurement range	-200 - 1090 °C
Battery type	AAA
Power source	Battery
Battery technology	Alkaline
Number of batteries supported	3
Operating altitude	0 - 2000 m
Maximum storage altitude	10000 m
Operating relative humidity (H-H)	0 - 80 %

Weight and Dimensions

Depth	198.1 mm
Width	100 mm
Height	6.35 mm
Weight	698.5 g
