Fluke 353 User Manual

353/355
Users Manual
6
Table 2. Features and Buttons (cont.)
Number Description
L
Backlight button - Turns the backlight on and off.
The backlight goes off after 5 minutes.
M Jaw release
N
Tactile barrier
XW Warning: To avoid injury, do not hold
the Meter anywhere above the tactile barrier.
O Display
P
Jaw wear indicator.
XW Warning: To avoid injury, do not use
the Meter if the wear indicator in the jaw
opening is not visible.
N/A
Auto Power Off- The Meter turns off if there is
no button pushed or rotary function switch
operation for 20 minutes. Turn the Meter off and
on to restart the Meter. This feature is disabled
when the Meter is in Min Max mode.
Table 3. Rotary Switch Positions
Rotary Switch Position 353/355
Position Function Position Function
OFF
Meter is powered
down
? AC current
A DC current
AC + DC
A
Combined ac +
dc (true rms)
current reading.
Additional Positions (355 Only)
Position Function Position Function
K AC voltage L DC voltage
V
AC + DC
Combined ac + dc
(true rms) voltage
reading.
R Continuity
Ω Resistance

Fluke 353 Specifications

General

DC voltage	1000 V
Low pass filter	Yes
DC current (max)	2000 A
Measuring category	CAT III 1000V, CAT IV 600V
AC current maximum resolution (probe)	1 A
Battery type	AA
Number of batteries supported	6
Certification	IEC 61010-2-032, CE, RoHS, EMI, RFI, EMC, IP42
Product color	Black, Red, Yellow
Operating altitude	0 - 2000 m
Non-operating altitude	0 - 10000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Depth	52 mm
Width	98 mm
Height	300 mm
Weight	814 g
