5320A
Getting Started Manual
8
Correction COMP Mode (Active Loop Compensation) (5320A/VLC only)
Residual Impedance Range ............................. 0 to 2 Ω
Maximum Test Current ..................................... <25/N A pk, where N equals number of UUT generated test current
periods.
Uncertainty of compensation .......................... (1 % + 15 mΩ) + uncertainty of selected resistance value. Uncertainty
is valid at the point in time when the COMP function is initiated.
Leakage Current Source
Range ................................................................. 0.1 to 30 mA
Resolution:
Passive Mode ................................................. 10 μA setting, 1 μA measurement
Differential Mode............................................. 10 μA setting, 1 μA measurement
Substitute Mode.............................................. 10 μA
Active Mode (5320A/VLC only)....................... 10 μA
Test Voltage:
Passive Mode ................................................. 60 to 250 V ac + dc rms
Differential Mode............................................. 60 to 250 V ac + dc rms
Substitute Mode.............................................. 10 to 250 V ac + dc rms
Active Mode (5320A/VLC only)....................... 50 to 100 V ac + dc rms
Uncertainty:
Passive Mode ................................................. 0.3 % + 2 μA ac + dc rms
Differential Mode............................................. 0.3 % + 2 μA ac + dc rms
Test uncertainty can be influenced by power line voltage instability
Substitute Mode.............................................. 0.3 % + 2 μA ac + dc rms
Active Mode (5320A/VLC only)....................... 0.3 % + 1 μA ac + dc rms
RCD (Residual Current Device)
Trip Current Range:
0.5 X I and 1 X I Mode .................................... 3 to 3000 mA in 1 mA steps
1.4 X I and 2 X I Mode .................................... 3 to 1500 mA in 1 mA steps
5 X I Mode ...................................................... 3 to 600 mA in 1 mA steps
Trip Current Measurement Resolution ........... 1 μA on 30 mA range
10 μA on 300 mA range
100 μA on 3A range
Uncertainty:
0.5 X I and 1 X I Mode .................................... 1 % rms
1.4 X I and 2 X I Mode .................................... 2 % rms
5 X I Mode ...................................................... 5 % rms
Trip Time Range................................................ 10 to 5000 ms
Trip Time Uncertainty....................................... 0.02 % + 0.25 ms
Series Resistance ............................................. 0.025 Ω, 0.05 Ω, 0.1 Ω, 0.33 Ω, 0.5 Ω, 1 Ω, 1.8 Ω, 5 Ω, 10 Ω, 18 Ω,
50 Ω, 100 Ω, 180 Ω, 500 Ω, 1000 Ω, 1800 Ω
Line/Touch Voltage Range............................... 250 V
Line/Touch Voltage Uncertainty...................... 5 % + 3 V
AC/DC Voltage Calibrator (5320A/VLC only)
Range ................................................................. 3 to 600 V, ac or dc
Resolution ......................................................... 4 digits
Internal Ranges:
AC Mode......................................................... 30, 100, 300, and 600 V (Autoranging only)
DC Mode......................................................... 30, 150, and 600 V (Autoranging only)
Frequency:
Range ............................................................. 40 to 400 Hz
Resolution....................................................... 3 digits
