Multifunction Electrical Tester Calibrator
Unpacking and Inspection
11
Unpacking and Inspection
WXWarning
The Calibrator is capable of supplying lethal voltages. To avoid
electric shock, do not touch the Calibrator’s output terminals.
Read this section before operating the Calibrator.
The Calibrator is shipped in a container that is specially designed to prevent damage
during shipping. Inspect the Calibrator carefully for damage, and immediately report any
damage to the shipper. Instructions for inspection and claims are included in the
shipping container.
If you need to reship the Calibrator, use the original container. If it is not available, you
can order a new container from Fluke by identifying the Calibrator’s model and serial
number.
When you unpack the Calibrator, check for all the standard equipment listed in Table 1.
Report any shortage to the place of purchase or to the nearest Technical Service Center.
Visit Fluke web site for Service Center locations.
If performance tests are required for your acceptance procedures, refer to Chapter 6 of
the 5320A Users Manual for instructions. Line power cords available from Fluke are
listed in Table 4 and illustrated in Figure 1.
Table 1. Standard Equipment
Item Model or Part Number
Multifunction Electrical Tester Calibrator 5320A or 5320A/VLC
Line Power Cord See Table 4 and Figure 1
5320A Getting Started Manual 2634331
5320A User Documentation CD (Getting Started &
Users Manuals)
2634346
10 KV Adapter – 1000:1 Voltage divider and
resistance multiplier.
2743421
Spare Fuses See Tables 2 and 3 for a list of fuses with part
numbers.
Cable adapter - Line plug to 3 banana plugs
[1]
2743368 (United Kingdom)
2743387 (Europe)
2743400 (Australia/New Zealand)
Cable adapter - Line socket to 3 banana plugs
[1]
2743379 (United Kingdom)
2743393 (Europe)
2743417 (Australia/New Zealand)
Test lead 1000 V/32 A/50 cm banana-banana red 2743442
Test lead 1000 V/32 A/50 cm banana-banana blue 2743439
Test lead 1000 V/32 A/50 cm banana-banana green 2743456
Test lead 1000 V/32 A/50 cm banana-banana black 2743463
Notes:
[1] Only one of the items in the right column ships with each Calibrator.
