5320A
Getting Started Manual
18
Table 5. Front-Panel Features (cont.)
Item Description
K TPUQK
The output adjustment controls. If any of these keys are
pressed or the knob is rotated, a digit on the Output Display
becomes highlighted and the output increments or
decrements as the knob is rotated. If a digit rolls past 0 or 9,
the digit to its left or right is carried.
When making a menu selection, pushing in on the knob is
equivalent to pressing the SELECT softkey. When editing a
number, pressing in on the knob will switch between moving
the cursor between characters and changing the selected
character’s value. Arrow icons above and below the selected
digit indicate which of the two modes are active.
The
T and U keys adjust the magnitude of changes by
moving the highlighted digit. The
P and Q keys increment
and decrement respectively the value of the selected digit.
L O S Controls the application of output signals to the output
terminals. The O and S have LEDs imbedded in them to
indicate whether or not the output signal is applied (Operate)
or not (Standby).
M 0 through 9 B D C
E
Contains number keys for keying in the output amplitude,
selecting menu items, as well as other data such as the time
and date. To enter a value, press the digits of the output
value, a multiplier key if necessary, and an output function
key; then press E.
XWWarning
To avoid electric shock, ensure the Calibrator is in standby
before making connections to the following terminals:
• HI and LO OUTPUT terminals for the Voltage function have up 600 V
ac or dc in operate mode.
• L, PE and N terminals have line voltage present when in operate for
the RCD and Z
L
modes.
