Fluke 5790B - Page 160

5790B
Service Manual
C-10
Group DC_7V
Name Default Function
DI_7V 1.0 7V range DAC volts per input volt
OF_7V 0.0 7V range DC offset
Group ZC_7V
Name Default Function
Z_7V 0.0 7V range zero
SHO_7V 0.0 7V AUX input offset
IA_7V 3.16228 7V range A/D volts per input volt
Group AC_7V
Name Default Function
F1_7V 1.0 7V range flatness correction 1 (10 Hz)
F2_7V 1.0 7V range flatness correction 2 (100 Hz)
F3_7V 1.0 7V range flatness correction 3 (1 kHz)
F4_7V 1.0 7V range flatness correction 4 (10 kHz)
F5_7V 1.0 7V range flatness correction 5 (20 kHz)
F6_7V 1.0 7V range flatness correction 6 (50 kHz)
F7_7V 1.0 7V range flatness correction 7 (100 kHz)
Group ZC_7VHF
Name Default Function
Z_7VHF 0.0 7VHF range zero
SHO_7VHF 0.0 7VHF AUX input offset
IA_7VHF 3.16228 7VHF range A/D volts per input volt
Group AC_7VHF
Name Default Function
F1_7VHF 1.0 7VHF range flatness correction 1 (100 kHz)
F2_7VHF 1.0 7VHF range flatness correction 2 (300 kHz)
F3_7VHF 1.0 7VHF range flatness correction 3 (500 kHz)
F4_7VHF 1.0 7VHF range flatness correction 4 (800 kHz)
F5_7VHF 1.0 7VHF range flatness correction 5 (1 MHz)
