Fluke 5790B - Page 162

5790B
Service Manual
C-12
Group DC_70V
Name Default Function
DI_70V 0.1 70V range DAC volts per input volt
OF_70V 0.0 70V range DC offset
Group ZC_70V
Name Default Function
Z_70V 0.0 70V range zero
SHO_70V 0.0 70V AUX input offset
IA_70V 31.6228 70V range A/D volts per input volt
Group AC_70V
Name Default Function
F1_70V 1.0 70V range flatness correction 1 (10 Hz)
F2_70V 1.0 70V range flatness correction 2 (100 Hz)
F3_70V 1.0 70V range flatness correction 3 (1 kHz)
F4_70V 1.0 70V range flatness correction 4 (10 kHz)
F5_70V 1.0 70V range flatness correction 5 (20 kHz)
F6_70V 1.0 70V range flatness correction 6 (50 kHz)
F7_70V 1.0 70V range flatness correction 7 (100 kHz)
F8_70V 1.0 70V range flatness correction 8 (300 kHz)
F9_70V 1.0 70V range flatness correction 9 (500 kHz)
F10_70V 1.0 70V range flatness correction 10 (1 MHz)
Group DC_220V
Name Default Function
DI_220V 0.05 220V range DAC volts per input volt
OF_220V 0.0 220V range DC offset
Group ZC_220V
Name Default Function
Z_220V 0.0 220V range zero
SHO_220V 0.0 220V AUX input offset
IA_220V 100.0 220V range A/D volts per input volt
