Fluke 5790B - Page 168

5790B
Service Manual
C-18
Group WAC_70MV
Name Default Function
F1_70MV_WB 1.0 70MV range, wideband input, flatness correction 1 (10 Hz)
F2_70MV_WB 1.0 70MV range, wideband input, flatness correction 2 (50 Hz)
F3_70MV_WB 1.0 70MV range, wideband input, flatness correction 3 (400 Hz)
F4_70MV_WB 1.0 70MV range, wideband input, flatness correction 4 (1 kHz)
F5_70MV_WB 1.0 70MV range, wideband input, flatness correction 5 (2 kHz)
F6_70MV_WB 1.0 70MV range, wideband input, flatness correction 6 (6 kHz)
F7_70MV_WB 1.0 70MV range, wideband input, flatness correction 7 (10 kHz)
F8_70MV_WB 1.0 70MV range, wideband input, flatness correction 8 (20 kHz)
F9_70MV_WB 1.0 70MV range, wideband input, flatness correction 9 (50 kHz)
F10_70MV_WB 1.0 70MV range, wideband input, flatness correction 10 (70 kHz)
F11_70MV_WB 1.0
70MV range, wideband input, flatness correction 11
(100 kHz)
F12_70MV_WB 1.0
70MV range, wideband input, flatness correction 12
(500 kHz)
F13_70MV_WB 1.0 70MV range, wideband input, flatness correction 13 (2 MHz)
F14_70MV_WB 1.0 70MV range, wideband input, flatness correction 14 (4 MHz)
F15_70MV_WB 1.0 70MV range, wideband input, flatness correction 15 (9 MHz)
F16_70MV_WB 1.0
70MV range, wideband input, flatness correction 16
(12 MHz)
F17_70MV_WB 1.0
70MV range, wideband input, flatness correction 17
(16 MHz)
F18_70MV_WB 1.0
70MV range, wideband input, flatness correction 18
(20 MHz)
F19_70MV_WB 1.0
70MV range, wideband input, flatness correction 19
(30 MHz)
F20_70MV_WB 1.0
70MV range, wideband input, flatness correction 20
(35 MHz)
F21_70MV_WB 1.0
70MV range, wideband input, flatness correction 21
(40 MHz)
F22_70MV_WB 1.0
70MV range, wideband input, flatness correction 22
(45 MHz)
F23_70MV_WB 1.0
70MV range, wideband input, flatness correction 23
(50 MHz)
