Table 7. Program Variables
Setting Name Description
Cycles CYCL Number of cycles. Range is 1 to 99. Default is 1.
Order ORD Setpoint order. Range is 0 (linear, default) or 1 (up/down).
Dwell Time DWEL Dwell time in minutes. Range is 1 to 900. Default is 10.
Ramp Rate RRAT Heating or cooling rate in °C per minute or °F per minute.
Ramp Enable RREN Turn ramp rate on or off. Range is 0 (off, default) or 1(on).
Points POIN Number of setpoints, 1 to 8. Default is 2.
Setpoint 1 SPO1 Setpoint temperature in °C or °F. Default is 40 °C or 104 °F.
Setpoint 2 SPO2 Setpoint temperature in °C or °F. Default is 40 °C or 104 °F.
Setpoint 3 SPO3 Setpoint temperature in °C or °F. Default is 40 °C or 104 °F.
Setpoint 4 SPO4 Setpoint temperature in °C or °F. Default is 40 °C or 104 °F.
Setpoint 5 SPO5 Setpoint temperature in °C or °F. Default is 40 °C or 104 °F.
Setpoint 6 SPO6 Setpoint temperature in °C or °F. Default is 40 °C or 104 °F.
Setpoint 7 SPO7 Setpoint temperature in °C or °F. Default is 40 °C or 104 °F.
Setpoint 8 SPO8 Setpoint temperature in °C or °F. Default is 40 °C or 104 °F.
Example:
PROG:DEF “My_Program”,2,0,5,1,0,3,0.0,50.0,100.0
This command is conditionally password protected.
The query returns the values of the parameters of the selected program in a
comma separated list.
PROGram:EXPlicit:DELete <name>
Delete the specified program.
<name> is the name of an existing program enclosed in quotation marks.
Since at least one program must be defined, a new default program will be
created if necessary.
This command is conditionally password protected.
PROGram:EXPlicit:EXEcute <name>
Run the specified program.
<name> is the name of an existing program enclosed in quotation marks.
No program may be running, otherwise the command will fail.
