Getting Acquainted with the Calibrator
11
Table 4. Key Functions
No Name Description
A O Turns the power on or off.
B l Selects voltage, mA or Loop Power measurement function in the upper display.
C A Selects the pressure measurement function in the upper display. Repeated pushes cycle
through the different pressure units.
D K Zeros the pressure module reading. This applies to both upper and lower displays.
E C Turns backlight on or off. Turns Contrast Adjust mode on when powering up.
F F Toggles frequency and ohms measurement and sourcing functions.
G D Toggles between Centigrade or Fahrenheit when in TC or RTD functions.
H G Recalls from memory a source value corresponding to 100 % of span and sets it as the
source value. Press and hold to store the source value as the 100 % value.
I H Increments output by 25 % of span.
J I Decrements output by 25 % of span.
K J Recalls from memory a source value corresponding to 0 % of span and sets it as the
source value. Press and hold to store the source value as the 0 % value.
Identifies Firmware version. Press and hold J when powering up.
