Fluke 773 Instruction Sheet

772/773/773-II English Instruction Sheet
Page 6

fjv05.emf
Number Description
A Detachable clamp
B
Tactile Barrier docked and un-docked. Refer to Safety Information
and Symbols.
C Display
D Measurement spotlight LED
Figure 2. The Milliamp Process Clamp Meter

Fluke 773 Specifications

General

Operating altitude	0 - 2000 m
Storage temperature (T-T)	-25 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	0 - 90 %
Battery type	AA
Power source	Battery
Battery voltage	1.5 V
Battery technology	Alkaline
Number of batteries supported	4
Product type	Digital multimeter
Product color	Grey, Red, Yellow
DC current range	0 - 0.024 A
DC voltage range	0 - 30 V
Placement supported	Handheld multimeter
Basic accuracy (DC current)	0.2% + 2 counts

Weight and Dimensions

Depth	44 mm
Width	70 mm
Height	246 mm
Weight	410 g
