Fluke 8021B - Controls, Indicators

8021
B
Table
2-1. Controls,
Indicators
and Connectors
(cont)
ITEM
NO.
NAME
FUNCTION
ments. This
connector
will accept
standard banana plugs.
5
COMMON
input
Connector
Protected
test lead
connector used as
the
low
or common input
for all
measurements.
This
connector will
accept
standard
banana plugs.
6
mA
input
Connector
Protected
test lead
connector used as
the
high input
for all
current
measurements.
This connector will
accept
standard
banana plugs.
7
mA/V-0
Switch
A push-push
switch
(push on
- push
off, do
not
pull
to
select
function)
which
operates in
conjunction
with the
high input
connectors to
select
either
the
mA/V or 0
measurement
functions.
When in or depressed
it selects
0. The
out
position selects mA
or V
depending
upon the
location of
the high input
lead.
8
Range
Switches
Interlocked push-button
switches for
selecting
ranges, i.e., pressing the
desired
range switch selects that range
and
cancels previous
switch
depressions. Do
not pull switches to
select a range.
Voltage:
200 mV,
2V, 20V,
200V,
1000V dc/750V ac
Current: 2
mA, 20 mA, 200 mA,
2000 mA
Resistance:
2000,
2 kQ, 20
kO, 200
kO,
2000
kQ, 20 MO
9
Tilt Bail
A
removable
fold-out stand
which
allows
the
instrument to be either
tilted
for
bench-top
applications
or hung
from a
hook in the
absence of a
work
surface.
10
DC/AC/J))) Switch
A
push-push switch
(push on
-
push
off, do not
pull
to
select function)
used
to
select the ac
or dc
measurement
function
when measuring
current or
voltage. When
in, or depressed,
the
ac
function is selected.
Out selects dc.
2-5
