Fluke 9062 User Manual

Motor & Phase Rotation Indicator
Using the Motor & Phase Rotation Indicator
11
See Table 2 for the minimum motor diameter and number of pole pair to obtain a reliable
test result.
Table 2. Reliable Motor Test Requirements
Rotary Number of Rotary Field (1/min) at
Frequency (Hz)
Angle Between
Poles
Min. ∅ of
Motorcase
Number
of Pole
Pair
16 2/3 50 60 ° cm
1 1000 3000 3600 60 5.3
2 500 1500 1800 30 10.7
3 333 1000 1200 20 16.0
4 250 750 900 15 21.4
5 200 600 720 12 26.7
6 167 500 600 10 32.1
8 125 375 450 7.5 42.8
10 100 300 360 6 53.5
12 83 250 300 5 64.2
16 62 188 225 3.75 85.6

Fluke 9062 Specifications

General

Housing color	Black, Yellow
Frequency range	2 - 400 Hz
3 phase indication	Yes
Operating altitude	0 - 2000 m
Phase display range	120 - 400 V
Operating voltage (max)	400 V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	15 - 80 %
International Protection (IP) code	IP40
Battery voltage	9 V
Number of batteries supported	1

Weight and Dimensions

Depth	27 mm
Width	61 mm
Height	124 mm
