COMMAND REFERENCE 4 - 59
HCOPy:DEVice
Syntax:
HCOPy:DEVice HPGL | HP7440 | HP7550 | HP7475A| HP7470A
| PM8277 | PM8278 | FX80 | LQ1500 | HP2225
| HPLASER | HP540 | DUMP_M1
HPGL HPGL plot data format.
HP7440, HP7550, HP7475A, HP7470A, Plotters.
PM8277, PM8278
FX80, HP2225, LQ1500, HPLASER, HP540 Printers.
DUMP_M1 Trace dump data
format to one of the
arbitrary waveform
generators PM5138,
PM5139, or PM5150.
Query form:
HCOPy:DEVice?
Response:
HPGL | HP7440 | HP7550 | HP7475A| HP7470A | PM8277
PM8278 | FX80 | LQ1500 | HP2225 | HPLASER | HP540 | DUMP_M1
Description:
The HCOPy:DEVice <n> command selects a hardcopy device by specifying the
device type. This selection determines the format of the hardcopy data that can
be read using the HCOPy:DATA? query.
After a
*
RST command, the hardcopy device selection is HPGL.
Example:
Send
→
*
RST Resets the instrument.
Send
→ HCOPy:DEVice PM8277 Selects the PM8277 plotter
Send
→ HCOPy:DATA? Requests for screen hardcopy data in
PM8277 plot format.
Read
← <data_block> Reads the hardcopy data block,
consisting of: #0<hardcopy_data>NL
Send <hardcopy_data> to the connected PM8277 plotter.
Front panel compliance:
The HCOPy:DEVice command is the remote equivalent of the front panel
UTILITY - PRINT/PLOT softkey menu.
