C.2 Glossary of Symbols Used
- µV = micro voltage (1E-6)
- dB = decibell
- dBm = decibell with respect to 1 mW
- dB
µV = decibell with respect to 1 µV
- Vrms = RMS voltage (Peak /
√2)
- Hz = Hertz
- m = meter
- Mbyte = Megabyte
- ms = milliseconds
- mw = milliwatt (1E-3)
- s = seconds
-% = percentage
- [ ... ] = Default program message part, which can be optionally specified.
This means that a program message may or may not contain the
defaulted keyword, without changing the semantic meaning of the
message.
- { ... } = Program message part that can be repeated (zero or more times).
- | = sign to indicate a choice (... or ...)
- ^ = Ctrl key, E.g.,, ^END means Ctrl + END
- = ’logical OR’ symbol (... or ...)
- = ’logical AND’ symbol (... and ...)
C.3 List of Tables
Table 3.1 The TRIGger modes (section 3.4.1.3)
Table 3.2 Relation between acquisition length and available trace memory
(section 3.10)
Table 3.3 The Operation Status bits (section 3.15.1.1)
Table 3.4 The Questionable Status bits (section 3.15.1.2)
Section 4.2 Command summary
Table 4.1 Display character set for CombiScope instruments
(DISPlay:WINDow2:..)
Table 4.2 MTB values in the digital mode (SENSe:SWEep:TIME)
Table 4.3 Reference numbers for front panel keys (SYSTem:KEY)
Appendix B.3 Cross reference functions/commands
Appendix E Summary of instrument settings per node.
&
